Ultimate
Kirtle Pattern
Lady Asrune Russtikus-dotta
Pennsic
whitneyasrune@gmail.com
Kirtle: (Kyrtel) is a fitted tunic-like
dress with variations found from the 1350s all the way up to 1650s. It was a staple of the medieval wardrobe.The Kirtle was worn by all different classes of women all over
Europe. Typically, a chemise, or
underdress, is worn
underneath. An overdress such as a “houplandie” or “cotehardie” would be worn on
top when needed.
The kirtle acts like a bra. The body of the dress can be 2, 4, 8 or
more pieces. They can be lined, or not. They can have long, short, or no
sleeves. They can have a waist seam, or not. They can be laced or buttoned, on
the side or in front. They can be elaborate or simple, heraldic or plain. In
short, there are a lot of options to work with when it comes to Kirtles that
are all “period,” and can be made with just one pattern!
The Pattern
(Draping method)
Fabric- Linen (most common),
Silk, or Wool. Leather is also
period, but rare. Avoid synthetic fabrics. You will need 3-8yds of fabric to make a kirtle. You will need 1-3yds
to make the pattern.
American Size Yards for dress Yards
for pattern
Size 2-6 3-4 1
Size 8-14 5-6 2
Size 16-24 6-8 3
Before you start- Make sure you have
·
Lots
of pins!
·
1-3yds
of linen (the lighter the color the better, so you can write on it)
·
Scissors
·
A
sharpie or fabric marker
·
A
friend to pin you up
·
And
a good bra on
Step 1: Take your measurements
Bust (A)
|
|
Waist (B)
|
|
Hip (C)
|
|
Sleeve (H)
|
|
Upper Arm (O)
|
|
Wrist (N)
|
|
Waist to floor (K-M)
|
|
1.
Divide you Hip measurement (C) by 4, add two inches and cut 4
rectangles of fabric of that width. This should make four large bits of fabric,
that combined are large enough to cover your back and front. They should be long enough to cover your bottom.
Hip/4 + 2in = Rectangle width
2.
Pin 2 rectangles together to
form the back of your pattern. Pin the other 2 together to make the front.
3.
Get a friend to center and pin the back and front pieces together at
the shoulders on you.
4.
Have you friend pin the sides closed, being careful to keep both sides
even. You should look like this:
5.
Pinch the fabric on the pined “seams,” to tighten the fabric around you
and re-pin. Work slowly, be careful to keep the sides even, and the front and
back centered.
6.
Tighten the shoulder until you feel “lifted”. You should look something
like this:
7.
Get
a sharpie or fabric marker, and mark:
l Your natural waist line. (An easy way to do
this is hold a string around you, it will automatically go to the smallest part
of your waist.)
l Where you want your neckline(s) to
be. High(neck), low(normal), and
sexy (boobs) are the three I usually mark.
TIP: if you leave the
neck high, you can use this pattern for a doublet too!
l The joint where your arm meets your shoulder. This is where your sleeve should start.
8.
Trace
all the pinned seams on both sides with your marker. Make sure
you get front, back, sides and shoulders, both sides.
9.
Remove
all the pins.
10.
Compare
the two front pieces and the two back pieces by laying them out. There will be
slight differences between them. Chose the front and back you like best, or try
to mediate between them. This will be your final pattern.
11.
Cut
the pattern out, leaving 5/8in (or whatever you like to use) seam allowance.
12.
Put your name, the date and your seam allowance on the pattern. Label
back and front and viola! You’re done!
1.
Make a “T” with your Sleeve
measurement. One line horizontal. One line vertical.
2.
Center your wrist measurement at the bottom.
3.
Center your Upper arm measurement at the top.
4.
Add seam allowance
5.
Measure 1 in down and 2 in up from the top of your “T” and draw a
curve OR…
6.
Better yet, take a piece of string,
measure the sleeve hole on your new made pattern and cut to the exact length on
string. Then move the string to fit a curve like the one above on your horizontal
“T” line.
The Chemise
Use the same
pattern as you did for the kirtle, but cut it on the bias for more stretch and no closures. If you don’t
have the fabric to do this, then add 1-3in to the width of the pattern. You may
also want a slightly looser sleeve.
Modifications:
1.
You can shorten the sleeves, simply cut off the sleeve pattern where you
want it.
2.
You can add gores to make a fuller skirt. I usually add 4 gores; front,
back, and sides, for the full “princess effect”
3.
You can also make it into more pieces, this makes a more fitted garment and
can help when you have narrow fabric width. It also serves to allow you to add
more gores. (think princess seams)
4.
Adjust the neckline shape.
5.
Use buttons instead of laces, you’ve got a cotehardie!
TIP: wrap pennies in bits of scrape fabric from your dress for the perfect
buttons!
6.
Try hand sewing your button holes by pushing a hole through the linen and
working your way around, you’ll be surprised how easy it is! (on that note, try
to avoid using metal grommets, they were not used on dresses in period)
7.
Cut the pattern off at the waist and make a doublet!
How you can use your kirtle pattern
drawings by Heather Morgan for this class, all right reserved
Kirtles in History
(in broad sweeping terms, not an end all be all)
Kirtles begin to appear in the early 1300s all over Europe. The fashion
seems to have started in the north and worked its way south to Italy by 1400. Like all fashions Kirtles are
first worn by the
upper class only, but work their way down to the lower classes fairly rapidly.
1350-1400: The most commonly seen kirtle
style from this time has short sleeves, a wide scoop neckline, no waist
seam and closes in the front, usually with laces. Solid colors. (This style of
Kirtle stays in fashion up until the 1450s with the lower
classes of women.)
1400-1450: Long sleeves become more common. Wide scoop neckline,
no waist seam, closes at the front usually with laces. They were mostly of solid color, but can
also be found in heraldic styles (such as quartering), cloth of gold, and other
patterned fabrics.
1400-1450: the neckline seems to narrow into
a closed scoop or a “V” shape, and side closures become more popular. We also
start to see the sleeveless kirtles, often with detachable sleeves. So you can “dress up” your look.
1450-1500+: brings the waisted kirtle into vogue. At first, the skirts attached to these
kirtles were pieced skirts that were wider at the hem and narrowed into the
waist. However, there is a rapid progression to gathered and then pleated
skirts. The waisted kirtle is used in many forms, for many styles all the way
into the 1650s.
Kirtles in Action
 |
| Front laced, classic Kirtle. Notice the fake sleeves. |
 |
| German style, the yellow kirtle is likely a side laced kirtle with a wide square neckline. The overdress or kampfrau uses the same pattern with a scoop neckline and a closed front lacing or hooks. |
 |
| waisted square neck sleeveless Kirtle, working class . Notice the wide lacing. |
 |
Two short sleeved working class kirtles. The left is a looser pull over gown, the right kirtle is front laced with a wide scoop neckline. You get a good look at the Chemise here too.
|
 |
| Waisted Kirtle |
 |
| Waisted Kirtle with short sleeves and box pleats |
 |
| Split Skirt |
 |
| Wide front lacing and cloth of gold underskirt with metal eyelets |
.jpg) |
| Heraldic Kirtles |
 |
| Bi-colored Kirtle. |
Alternative Pattern theories:
The Quick and Dirty Geometric
Method-Some people will swear by this method as the “most
period” due to its simplicity, and there are some extant examples....but there are extant examples of other styles as well. It is a perfectly wonderful way to make a early period kirtle, it is NOT however form fitting enough to be a bra substitute. In my opinion it's a less
flattering method as a result, but great for looser wear-around-the-camp dresses.
1.
Fold
you fabric lengthwise.
2.
Divide
your Hip measurement by 4 use that for width of rectangles
3.
Cut
either 2 large rectangles (leave the fold), OR 4 smaller rectangles (cut on
fold)*
4.
Cut
4 gores, the height of your waist to floor (W-F) measurement, and width
desired.
5.
Cut
2 rectangular sleeves the width of your arm-2 +1 in.
6.
For
long sleeves, make sleeve as long as arm-1 + 1in, and narrow to wrist + 1in
7.
Cut
2 diamond shaped gussets 2-4in across.
*if you would like a front lacing kirtle, you must cut at lease the
front into 2 pieces.
Measure and draft Method
1. Patterning the good old fashion way! Instead of draping,
take all of your measurement form the first chart and plot them out on graph paper.
Continue as before. This method is great if you don't have a buddy. If you measure very carefully, you'll get something very close to the form-fitting Kirtle like you would get from draping. I find that this method doesn't always produce the support that I want, and generally has more wrinkles but they still look nice!
